1050mm Smart Pit™ Manhole

The Smartstream Smart Pit ™ is an Australian designed, produced and manufactured Polyethylene (PE) Manhole using Finite Element Analysis. The unit’s physical properties have been proven in service in various installation scenarios.

Please find below more information about this product.

DOCUMENTATION DOWNLOAD
Loading...

Smartstream Smart Pit™ is an Australian designed, produced and manufactured Polyethylene (PE) Manhole using Finite Element Analysis. The unit’s physical properties have been proven in service in various installation scenarios.

The Smart Pit ™ is made from the same PE material as that of the Smartstream Poo Pit™ maintenance shaft and is capable of handling the most corrosive internal and external environments with no requirement for expensive lining systems. The Smart Pit ™ is also suitable for use in sewer, stormwater and subsoil drainage applications and is compatible with PE, PVC, Polypropylene, clay or concrete piping materials.

In addition to offering the major benefit of corrosion resistant PE material, the Smart Pit ™ shares an extensive range of key features, which include; accommodating for inlets at any grade and angle, connections possible in base and/or riser, accommodating pipes of all material types, fast installation for retrofit and replacement projects, 100% watertight, lightweight user friendly, with reduced transport and handling costs. Additionally, the Smart Pit ™ offers easy connection of new lines.

Based on your project specifications, the Smart Pit ™ can achieve the exact angle and grade to suit the design or retrofit location and can be supplied with multiple inlets in the base or riser. Supplied to site fully welded with all connections pre made, reducing installation, handling and transports costs.

Each Smart Pit ™ is supplied fitted with a high visibility yellow safety bench providing a consistent 200mm non slip self- draining platform eliminating the need for post installation benching on site.

Quality
ISO 9001 -2015



Features & Benefits

  • Corrosion resistant PE material
  • No internal or external coatings required
  • Supplied fitted with non-slip bench
  • Accommodates inlets at any grade and angle
  • No horizontal/vertical alignment adjusting bends needed
  • Connections possible in base and or riser
  • Accommodates pipes of all material types
  • Suitable for welded connection to Polyethylene pipes
  • Made to suit either solvent weld or rubber ring PVC
  • Multiple pipe material connections possible on the same pit
  • All Smartpits prefabricated prior to delivery
  • Fast installation for retrofit and replacement projects
  • 100% watertight. All factory welded prior to delivery
  • Proven operational technology to depths of up to 5m
  • Lightweight and user friendly
  • Reduced transport and handling costs
  • Improved efficiencies providing cost benefits to the end user
  • UV resistant, state of the art Polyethylene technology
  • No concrete encasement required
  • Easy connection of new lines
  • No onsite welding or spark testing required

Installation

To download the Smartpit™ Installation Guide Click Here

Technical Information

Smartpit™ Drawing (Flat Top No Steps) SST-00003-A(C)

Smartpit™ Drawing (Flat Top With Steps) SST-00008-B(C)

Smartpit™ Drawing (Taper Top No Steps) SST-00003-B(C)

Smartpit™ Drawing (Taper Top With Steps) SST-00008-A(C)
